stainless steel

1.4906 / X12CrMoWVNbV10-1-1stainless steel

Name: 1.4906 / X12CrMoWVNbV10-1-1stainless steel
Brand: www.chuansteel.com
Availability: InStock
Rating: 5 (1 reviews)

1.4906 chemical composition; 1.4906 mechanical properties; 1.4906 application; 1.4906 heat treatment; 1.4906 specification; 1.4906 package and shipment

INQUIRY

Description

Package

steel grade:

1.4906 X12CrMoWVNbV10-1-1

1.4906 X12CrMoWVNbV10-1-1 chemical composition

C	0.10-0.14
Si	0.10 max
Mn	0.40-0.60
P	0.015 max
S	0.007 max
Cr	10.00-11.00
Ni	0.60-0.80
Mo	1.00-1.20
V	0.15-0.25
Nb	0.04-0.060
W	0.95-1.10
N	0.040-0.060
Al	0.012

X12CrMoWVNbV10-1-1 Mechanical Properties


Tensile strength Rm （MPa）	700-850	800-950	930-1000
Yield strength Rp0.2（MPa）min	600	700	930
Elongation A（%）min	18	15	14
Reduction of area Z（%）min	50	45	40
Charpy AKv min	40	30	25

1.4906 Specifications：

steel round bar : dia 2mm to 1000mm

Square-shape steel: 50mm to 600mm

Steel sheet: thickness 0.5mm-12mm width 1000mm max

Steel strip: thickness 0.5mm-4mm   width 300mm max

steel plate : thickness 5mm-800mm    Width: 10mm to 1000mm

steel pipe: OD 8-800mm

Length: random length/ fixed length

Delivery condition: hot forged / hot rolled /cold-rolled

annealing/normalizing + tempering/quenching + tempering/ solution

Surface : black/ground/rough turned/fine machining/Peeled / mill-fimish surface

metallurgical processing: electrode arc + LF/VD/VOD/ESR/ VIM/ VAR

Ultrasonic inspection: 100% ultrasonic test
